技術特性：
1.適用于EVA制品的冷壓成型，如EVA鞋墊等
2.采用框架式結構設計，承受壓力大，抗張力強，使用壽命長
3.具有整體結構合理，外形美觀，上升速度快，省電，工作壓力易調，操作簡單，機械性能安全可靠，穩定性好等優點
4.冷卻采用雙向式冷卻，循環效果快速均勻
|
技術規格：Technical
specifications
|
|
|
|
型號 Model
|
GY990908A3
|
GY990908A4
|
|
模板尺寸 Platen size
|
320*450㎜
|
550*450㎜
|
|
模座數 Number
of die bases
|
3
|
6
|
|
最大油壓出力 Max.oil
pressure output
|
80T
|
100T
|
|
油缸缸芯直徑 Cylinder core diameter
|
6″
|
8″
|
|
最大功率 Maximum power
|
7.5KW
|
10KW
|
|
輸入電壓/頻率 Input voltage
|
380V/50HZ/60HZ
|
380V/50HZ/60HZ
|
|
主機尺寸 Machine dimensions
|
3000*1200*1910mm
|
5860*1200*1910mm
|
|
裝箱尺寸 Packaging imensions
|
3100*1300*2010mm
|
5960*1300*2010mm
|
|
凈重/毛重 Net/gross weight
|
2000*2100kgs
|
7000/7600kgs
|
Technical features:
1.Applicable to cold pressed forming of EVA products ,such as EVA movable shoe pad
2.Portal structured(framework)，with high bearing capacity,powerful tensile stress,and long service life
3.With the overall structure is reasonable,Beautiful shape ,rising fast ,save electricity,working pressure easily adjustable,the operation is simple,mechanical properties of safe and reliable,good stability, etc
4.Equipped with a bi-directional cooling system,Cooling effect quickly and evenly
