適用范圍：

本機專用于無紡布、襯布、包袋、煙標、掛歷、紙張、塑料薄膜等產品的氣壓沖孔。沖孔形狀可按用戶要求訂做。客戶須自行配置氣源。

技術參數：

有效沖孔寬度：350毫米（可定制不同寬度）

有效沖孔厚度：塑料0.1～0.8mm   紙張50g～300g

定長精度：±0.2mm                     最高沖孔速度：80米/分鐘

整機總功率：2kw                       電壓：220V/380V可選

配備特點：

1.采用進口PLC及進口高精密伺服或步進系統控制沖孔定位，定位精度達到0.2mm，送料平穩均勻，并有電機故障診斷及保護功能。

2.操作界面采用LCD中文顯示屏，所有操作，只需要一個畫面，可同時設定沖孔間距、次數和批次，并顯示實際沖孔次數和批次、聲光報警，并設有手動/自動轉換功能

3.可同時沖二卷材料，并可安裝二套氣壓沖孔模具，左右自由定位，速度可提高一倍。

4.收卷牽引采用收料直流電機+浮動輥結構，合理的結構和電器控制保證收料過程中張力的穩定.可保證材料最小的拉伸變形。

5.集中電氣控制箱,電氣元件分布合理,每條線都做有記號，診斷維修簡單快捷，不易出故障，控制系統更為可靠.

Applications:

his machine is dedicated to non-woven fabric, lining, bags, enlarging, calendars, paper, plastic film products such as air punching. Punch shape can be customized to user requirements. Customers are required to configure their own air supply.

Technical Parameter:

Effective punching width: 350 mm(can be customized in different widths)

Effective punching thickness: Plastic 0.1 ~0.8mm    paper50g ~300g

Length accuracy: ±0.2mm

Maximum punching speed: 80 m/ min

Total power: 2kw  Voltage: 220V/380V optional

Features:

1.Using imported PLC and imported high-precision control of servo or stepper system, punching position, the positioning accuracy of0.2mm , smooth, even feeding, and motor fault diagnosis and protection.

2.Interface with LCD Chinese display, all operations, only one screen, which can set the punching distance, frequency and batch, and batch number and show the actual piercing, audible alarm, and with manual / automatic conversion

3.Vols material can be washed at the same time, and install two sets of barometric pressure punching mold, so free position, speed can be doubled.

4.The use of close material rolling traction DC motor + floating roller structure, reasonable structure and electrical controls to ensure that the process of rewinding tension stability. Guaranteed minimum tensile deformation of materials. .

5.Focus on the electrical control box, a reasonable distribution of electrical components, mark each line are doing a diagnostic repair quick and easy, not easy to fail, the control system more reliable
