主要技術參數(shù) Main Technical PARAMETERS
●TANK容量：7kg
●幫浦功率：齒輪90W-40K
●操作溫度：最高210℃
●整體耗電量：2600W
●電力需求：220VAC/單相
●出膠功率：54kg/hr
●機體重量：45kg
●風壓范圍：槍體：4.5kg
●融膠能力：11kg/hr,3000CPS
●機體尺寸：520X350x630
◆TANK CAPACITY:7kg
◆PUMP POWER:Gear Pump 90w-40k
◆OPERATING TEMPERATURES:MAX 210℃
◆POWER CONSUMPTION:2600W
◆OPERATING POWER:220VAC/single phase
◆EJECTING CAPACITY:54kg/hr
◆WEIGHT:45kg

◆WIND PRESSURE RANGE:Inside cylinder:4,5kg
◆MELTING CAPACITY: 11kg/hr,3000CPS
◆DIMENSION: LxWxH 520x350x 630
功能特點 Functions and features
●Gearpump高強度鋁合金成型、耐磨。出膠持久性佳、壽命長。
●電路故障檢知：維持機器使用效率并使熱融膠品質(zhì)穩(wěn)定。
●控溫精度準確，TANK分上、中、底層各別控溫，PID溫度差±1℃降低碳化機會。
●可依TANK容量選擇幫浦系統(tǒng)，或預約訂購特殊容量。
◆The Gear pump made of aluminium alloy of high intensity is wearresisting producs endurable adhesive and has long service life.
◆It checks up the circuit breakdown: keeps the machine efficient to make the hot melt adhesive stable.
◆It controls the temperature accurately, the tank is divided into upper,middle and lower beds, whose temperatures are separately controlled.PID temperature difference 10±1℃ reduces possible carbonization.
◆You can choose bump sets by tank capacity or place an order for special capacity.
